RMTS Series Rolling Mill Thrust Bearing is a high-performance multi-row tapered roller bearing engineered specifically to handle extreme axial (thrust) loads in heavy-duty metal rolling equipment.
The main material options for rings and rolling elements include GCr15,GCr15SiMn with hardness HRC 60-64,and G20Cr2Ni4A carburized steel for improved wear resistance.Cage selections cover machined brass for heavy load stability and 45# steel.Shaft diameter ranges from 100 mm to 1500 mm,housing bore spans 150 mm to 1800 mm,and height dimension falls between 30 mm and 300 mm.Available accuracy grades are P5 and P4.
These bearings deliver maximum axial load capacity up to 10000 kN.Advanced material treatment raises fatigue resistance by 40 percent.Pre-aligned structural design shortens installation setup time.Standard models can adopt oil jet lubrication or grease lubrication according to actual working conditions.Customized solutions for special material and sealing requirements are also available.
Metal Cutting & CNC Machine Tools
Main Milling & Turning Spindles:Primary support for high-speed CNC milling shafts,lathe spindles,and multi-tasking machining centers.
Grinding Spindles:Supports internal,external,and surface grinding shafts where sub-micron surface finish and zero chatter are required.
High-Speed Boring & Drilling Heads:Provides precise axial guidance during deep-hole drilling and fine boring operations.
Woodworking Plastics & Composite Processing
High-Speed Router Spindles:Handles sustained rotational speeds up to 40,000 RPM on CNC wood routers and composite machining centers.
Edge Bander & Trimming Heads:Maintains vibration-free cutting under continuous,high-speed material feeds.
Semiconductor Optics & Precision Manufacturing
Silicon Wafer Dicing Spindles:Supports ultra-high-speed air/electric spindles used for dicing silicon wafers and micro-glass substrates.
Optical Lens Grinding & Polishing:Delivers mirror-finish surface accuracy on optical lenses and mold cores.
Robotics Automation & Aerospace
High-Frequency Motor Spindles:Direct-drive motorized spindles for high-speed robotic deburring,engraving,and aluminum aerospace milling.
Test Rig Dynos & Gyroscope Shafts:High-precision rotational support in aerospace test benches and inertial guidance equipment.
Metal Cutting & CNC Machine Tools
Main Milling & Turning Spindles:Primary support for high-speed CNC milling shafts,lathe spindles,and multi-tasking machining centers.
Grinding Spindles:Supports internal,external,and surface grinding shafts where sub-micron surface finish and zero chatter are required.
High-Speed Boring & Drilling Heads:Provides precise axial guidance during deep-hole drilling and fine boring operations.
Woodworking Plastics & Composite Processing
High-Speed Router Spindles:Handles sustained rotational speeds up to 40,000 RPM on CNC wood routers and composite machining centers.
Edge Bander & Trimming Heads:Maintains vibration-free cutting under continuous,high-speed material feeds.
Semiconductor Optics & Precision Manufacturing
Silicon Wafer Dicing Spindles:Supports ultra-high-speed air/electric spindles used for dicing silicon wafers and micro-glass substrates.
Optical Lens Grinding & Polishing:Delivers mirror-finish surface accuracy on optical lenses and mold cores.
Robotics,Automation & Aerospace
High-Frequency Motor Spindles:Direct-drive motorized spindles for high-speed robotic deburring,engraving,and aluminum aerospace milling.
Test Rig Dynos & Gyroscope Shafts:High-precision rotational support in aerospace test benches and inertial guidance equipment.
Newbeetrans is a professional manufacturer for RMTS series rolling mill thrust bearings for metallurgical industry.The complete production workflow includes independent research and development,forging,heat treatment,ultra-precision grinding and specialized heavy-load performance testing laboratories under ISO 9001 quality management certification.
Stock and Customization Capacity
Mainstream standard RMTS bearing models are kept in stock for prompt delivery.Our technical team supplies comprehensive custom services including material replacement,dimension modification,sealing upgrade and special lubricant matching.Custom manufacturing cycle will be evaluated based on drawing complexity and raw-material supply situation.
Strict Full-Process Quality Assurance
Each incoming raw material batch completes spectral and metallurgical inspection.Every finished RMTS rolling mill thrust bearing undergoes one hundred percent testing including dimension measurement,load capacity simulation,friction assessment and sealing performance check.Material certificates and SGS third-party inspection reports can be provided on client request.
Advanced Production Infrastructure
Heavy-duty bearing dedicated grinders,specialized assembly fixtures and heavy-load test benches are equipped in-house.MES production management system realizes full batch traceability to guarantee consistent P5 and P4 precision standards.
Global Sales and Technical Support
We cooperate with worldwide sea freight and air freight service providers and support FOB,CIP,DAP and other standard international trade terms.Our engineers deliver remote model-selection consultation,installation guidance and lubrication scheme suggestion for global metallurgical plant and rolling mill equipment manufacturers.
For technical specifications,pricing,or custom bearing solutions:
