Structural Types:
Cage: Split two-piece hardened steel stamping structure
Guide Components: Central guide ring
Materials: Hardened steel (hardness adapted to high-speed and heavy-load requirements)
Size Range:Adapted Roller Diameter: Matched according to specific models (adapted to common bearing roller specifications)
Delivery Cycle:
7-15 days. For customized models, prior communication is required, and the delivery cycle will be arranged according to customization requirements.
| Parameter | Specification | Remarks |
| Cage Type | Two-piece hardened steel stamping | Nitrided surface treatment |
| Roller Type | Symmetrical spherical rollers | GCr15 or hybrid ceramic options |
| Inner Ring Design | Flangeless with center guide ring | Axial positioning ±0.05mm |
| Dynamic Load Capacity | 20%-35% higher than standard designs | Depends on bearing series |
| Max. Speed (Oil) | Up to 15,000 rpm | Depends on lubrication method |
| Operating Temperature | -40°C to +180°C | Suitable for wide thermal ranges |
| Hardness (Cage) | HRC 58-62 | Surface hardness after heat treatment |
| Precision Grade | P4 / P2 | Radial runout ≤0.005mm |
| Dynamic Balance | G2.5 | For high-speed applications |
| Lubrication Options | Grease (PAO synthetic) / Oil (circulating system) | Customizable based on application |
| Bore Diameter Range | 30 - 600 mm | Custom sizes available |
| Outer Diameter Range | 50 - 800 mm | Custom sizes available |
| Cross-Section Height | 12 - 80 mm | Thin-section designs available |
| Material (Rollers) | GCr15 (HRC 60-62) or ceramic | Ceramic reduces friction & heat |
| Material (Cage) | High-strength alloy steel | Nitrided for wear resistance |
| Vibration Levels | ≤1.5 mm/s @ 15,000 rpm | Tested per ISO 10816-3 |
| Service Life (L10) | >30,000 hours (at ≤50% Cr load) | Based on standard operating conditions |
Symmetrical roller layout + center guide ring increases dynamic load capacity by 20%-35%, outperforming traditional cages in shock resistance.
Dual-cage design minimizes roller collisions, reducing friction torque by 30% and improving thermal management
G2.5 dynamic balance ensures vibration ≤1.5 mm/s at 15,000 rpm.
Works with grease/oil lubrication and operates in -40℃~180℃ temperature ranges.
Wind Power Equipment: Planetary gear support bearings in main gearboxes.
Industrial Drives: High-speed rolling mill spindles, crusher rotors.
Aerospace: Main rotor bearings in helicopters.
Energy Machinery: Turbocharger shafts in gas turbines.
