Materials:
Rings & Rolling Elements: GCr15SiMn (HRC 62-64) / Carburized steel (2-3mm hardened layer).
Cage: Copper alloy (high-temperature resistance) / PA66 engineering plastic (lightweight & wear-resistant).
Size Range:
Inner Diameter: 35mm-200 mm
Outer Diameter:80 mm-360 mm
Width:19.213 mm-144 mm
Accuracy Classes: P5,P4.
Sealing Options: Open type (forced oil lubrication) / Labyrinth seal (IP65 protection).
Delivery Time: 7-15 days (standard), 3-6 weeks (customized).
Compatible with 24/7 operation, failure rate <0.1%.
50% lifespan extension via carburizing (HRC 60-62), regreasing interval up to 3,000 hours.
40% lower cost than FAG/INA, 30% shorter lead time.
| Bearing Dimension Table for High-Speed Wire Rod Rolling Mills | |||||||
| Code | Bearing Model | Dimensions (mm) | Weight (kg) | Bearing Type | Installation Location | Rated Load (KN) | Maximum Rotational Speed (rpm) |
| d | D | B | r | ||||
| 162250B | N 140-106 | 200 | 320 | 48 | 2.1 | 15 | Cylindrical Roller Bearing |
| 162250C | 7266 PD-9/6B | 130 | 230 | 80 | 3 | 14.5 | Angular Contact Ball Bearing (Paired) |
| 162250D | N 128-107 | 140 | 220 | 35 | 2 | 5.3 | Cylindrical Roller Bearing |
| 162250E | 7224 PD-9/6B | 120 | 215 | 80 | 2.1 | 12.4 | Angular Contact Ball Bearing (Paired) |
| 162250F | N 1024 | 120 | 180 | 28 | 2 | 2.8 | Cylindrical Roller Bearing |
| 162250G | N 126 KC10/7 | 130 | 200 | 33 | 2 | 3.6 | Cylindrical Roller Bearing |
| 162250H | N312 C4/2 | 60 | 130 | 31 | 2.1 | 1.9 | Cylindrical Roller Bearing |
| 162250HA | N 312 C5/3 | 60 | 130 | 31 | 2.1 | 1.9 | Cylindrical Roller Bearing |
| 162250J | 7310 PD7/5B | 50 | 110 | 54 | 2 | 2.5 | Angular Contact Ball Bearing (Paired) |
| 162250K | 309 RD9/6B | 45 | 100 | 50 | 1.5 | 1.9 | Angular Contact Ball Bearing (Paired) |
| 162250KA | 309S 34/26 | 45 | 100 | 25 | 1.5 | 1 | Deep Groove Ball Bearing |
| 162250L | 7208 PD5/4F | 40 | 80 | 36 | 1.1 | 0.8 | Angular Contact Ball Bearing (Paired) |
| 162250LA | 7309 PD7/5F | 40 | 100 | 50 | 1.5 | 2.1 | Angular Contact Ball Bearing (Paired) |
| 162250MA | QJ311Y | 50 | 120 | 49.213 | 2 | 2.8 | Four-Point Contact Ball Bearing |
| 16225CMB | 7310 PD8S | 50 | 110 | 54 | 2 | 2.5 | Angular Contact Ball Bearing (Paired) |
| 162250S | N134-104 | 170 | 265 | 42 | 2.5 | 8.3 | Cylindrical Roller Bearing |
| 162250U | 134KS | 170 | 260 | 42 | 2.1 | 8.4 | Deep Groove Ball Bearing |
| 162250V | N 228 | 140 | 250 | 42 | 2.5 | 8.7 | Cylindrical Roller Bearing |
| 162250W | 6228 | 140 | 250 | 42 | 3 | 9.1 | Deep Groove Ball Bearing |
| 162250X | 9128 KS2 | 140 | 210 | 33 | 2 | 4.1 | Deep Groove Ball Bearing |
| 162250A | 7334 PD-1b | 170 | 360 | 144 | 4 | 72 | Angular Contact Ball Bearing (Paired) |
| 162250GB | n 126 KC9/6 | 130 | 200 | 33 | 2 | 3.6 | Cylindrical Roller Bearing |
| 162250GC | nr 126 KC6/4 | 130 | 200 | 46 | 2 | 5.1 | Cylindrical Roller Bearing |
| 16225CHB | NR 312 KC11/7 | 60 | 130 | 46 | 3.1 | 3 | Cylindrical Roller Bearing |
| 162250HI | NU1211C | 50 | 100 | 27 | 2 | 0.9 | Cylindrical Roller Bearing |
| 162250JA | 7311 PD6/3B | 55 | 120 | 58 | 2 | 3.2 | Cylindrical Roller Bearing |
| 162250LB | 7307 PD8/4F | 35 | 80 | 42 | 1.5 | 1 | Cylindrical Roller Bearing |
| 162250Y | 7126 KRD4/2S | 130 | 200 | 33 | 2 | 3.8 | Cylindrical Roller Bearing |
High-speed wire rod mills: Split-speed boxes, speed-increase boxes, pinch rolls, cone boxes, roll boxes, laying heads.
Drive systems: Long shafts, idler wheels, reducing/sizing mills, gear split-speed boxes.
Compatible Models: Morgan 5th-gen, SMS 6th-gen, Danieli high-speed mills.
